Zebra ZM400 Series User Manual

343
Corrective Maintenance
Peel Rewind Option
8/9/07 ZM400/ZM600 Maintenance Manual 14207L-001 A
2. Install, but do not tighten, the main frame mounting screws provided in the kit.
3. Recheck the alignment from step 1 and then tighten the two screws on the rear of the main
frame.
4. Tighten the rest of the main frame mounting screws.
5. Reinstall the rear cover by sliding it under the screw loosened previously on the main
frame. Leave the screw loose.
6. Using the two screws supplied in the kit, attach the rear cover to the rewind pan.
7. Tighten the two screws and the one screw on the main frame.
Note • The oversize mounting hole in the pan allows for adjustment of the front of the pan
to align with the door.

Zebra ZM400 Series Specifications

General

Max Print Width	4.09 inches (104 mm)
Max Print Speed	10 inches per second (254 mm per second)
Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi (8 dots/mm)
Connectivity	USB 2.0, Serial RS-232, Parallel, Internal Ethernet (10/100), optional wireless
Media Width	1"/25.4 mm to 4.5"/114 mm
Media Length	0.25 to 39 inches (6 to 991 mm)
Media Thickness	0.0023"/0.058 mm to 0.010"/0.25 mm
Ribbon Width	1"/25.4 mm to 4.33"/110 mm
Ribbon Length	1476 feet (450 m)
Supported Media Types	Continuous, die-cut, notch, black-mark
Operating Temperature	40°F to 105°F (5°C to 40°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
