Corrective Maintenance
Peel Rewind Option
346
14207L-001 A
ZM400/ZM600 Maintenance Manual
8/9/07
Figure 207 • Inst
all the Motor and Spindle Assembly
6.
Alig
n the other access hole of the rewind back
plate to the other mounti
ng hole on the
rewind support plate
.
7.
Install the mounting screw an
d tighten.
8.
Tigh
ten the screw instal
led in
step 5
.
1
Access hole
2
Rewind back plate
1
1
2
2
345
347
