Zebra ZM400 Series User Manual

453
Drawings and Parts
Platen Housing
8/9/07 ZM400/ZM600 Maintenance Manual 14207L-001 A
Table K • Platen Housing
Item Part Number Description Qty
1
79862M
ZM400/ZM600 Platen Coupling Maintenance Kit 1
2
HW06250
E-ring, 0.312 external (sold in quantities of 100) 1
3
HW79554
Flat Washer, 0.33 × 0.69 × 0.03 (sold in quantities of 100) 1
4
79252
Roller Bearing 2
5
79815M
ZM400 Platen Roller Maintenance Kit 1
79816M
ZM600 Platen Roller Maintenance Kit 1
6
79819M
Printhead Latch Maintenance Kit 1
7
79659
Plug, 0.486 diameter hole 1
8
79606
Shoulder Screw, 4M × 5.5 × 2 1
9
79541
Curved Washer, 0.216 × 0.423 × 0.010 1
10
79741
Screw, M4 × 0.7 × 12* 1
11
HWQ10011
Screw, M4 × 0.700 × 10 (sold in quantities of 100)* 1
12
HW78806
Flat Washer, M4 (sold in quantities of 25)* 1
13
79700
Stabilizer* 1
14
78810
Adjustment Screw, M4 × 0.7* 1
15
77276
Latch Plate Cap* 1
16
HW49185
Screw, M3 × 0.5 × 6 (sold in quantities of 10) 1
17
77921
Cam 1
18
77919
Gauge Pins 2
19
79837M
ZM400 Tear Bar Maintenance Kit 1
79838M
ZM600 Tear Bar Maintenance Kit 1
20
HW77231
Screw, M3 × 8 (sold in quantities of 10) 2
Bold = Part available for purchase
Light italic = Part not available for individual purchase, listed and shown for reference only
Boxes = Parts contained in kits listed above
*.Part of print mechanism

Zebra ZM400 Series Specifications

General

Max Print Width	4.09 inches (104 mm)
Max Print Speed	10 inches per second (254 mm per second)
Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi (8 dots/mm)
Connectivity	USB 2.0, Serial RS-232, Parallel, Internal Ethernet (10/100), optional wireless
Media Width	1"/25.4 mm to 4.5"/114 mm
Media Length	0.25 to 39 inches (6 to 991 mm)
Media Thickness	0.0023"/0.058 mm to 0.010"/0.25 mm
Ribbon Width	1"/25.4 mm to 4.33"/110 mm
Ribbon Length	1476 feet (450 m)
Supported Media Types	Continuous, die-cut, notch, black-mark
Operating Temperature	40°F to 105°F (5°C to 40°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
