Zebra ZM400 Series User Manual

Operations
Control Panel Parameters
88
14207L-001 A ZM400/ZM600 Maintenance Manual 8/9/07
ZPL and XML only Format Memory Card
This option erases all previously stored information from the optional
64 MB flash chip on the Wireless Plus option board. This parameter
appears only when a Wireless Plus option board with the flash chip
populated is installed.
Caution • This option completely erases the flash chip.
To format a memory card:
1. Press SELECT to select the parameter.
2. Press
PLUS (+) to select A:.
If your printer is set to require a password, you are prompted to enter
the password.
3. Enter the password. For instructions, see Change Password-Protected
Parameters on page 74.
4. Press the appropriate button again to select the desired card.
The display shows
ARE YOU SURE?.
5. Do you want to continue?
• Press
MINUS (-) to select NO to cancel the request and return to
FORMAT CARD prompt.
• Press PLUS (+) to select YES and begin initialization.
When initialization is complete, the control panel displays
FORMATTING CARD COMPLETED.
Note • Depending on the amount of memory in the memory card,
initialization may take up to 5 minutes to complete.
6. Press
SELECT to deselect the parameter.
Table 12 • Printer Parameters (Page 11 of 24)
Parameter
Action/Explanation

Zebra ZM400 Series Specifications

General

Max Print Width	4.09 inches (104 mm)
Max Print Speed	10 inches per second (254 mm per second)
Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi (8 dots/mm)
Connectivity	USB 2.0, Serial RS-232, Parallel, Internal Ethernet (10/100), optional wireless
Media Width	1"/25.4 mm to 4.5"/114 mm
Media Length	0.25 to 39 inches (6 to 991 mm)
Media Thickness	0.0023"/0.058 mm to 0.010"/0.25 mm
Ribbon Width	1"/25.4 mm to 4.33"/110 mm
Ribbon Length	1476 feet (450 m)
Supported Media Types	Continuous, die-cut, notch, black-mark
Operating Temperature	40°F to 105°F (5°C to 40°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
