Zebra ZM400 Series User Manual

Operations
Control Panel Parameters
96
14207L-001 A ZM400/ZM600 Maintenance Manual 8/9/07
Select Media Power-Up Option
This parameter sets the action of the media when you turn on the printer.
Default Value: CALIBRATION
Selections: CALIBRATION, SHORT CAL, LENGTH, NO MOTION,
FEED
• Calibration adjusts sensor levels and thresholds, determines length,
and feeds the media to the next web.
• Short Cal sets media and web thresholds without adjusting sensor
gain, determines length, and feeds the media to the next web.
• Length determines label length using current sensor values, and feeds
the media to the next web.
• No Motion tells the printer not to move the media. You must
manually ensure that the web is positioned correctly, or press feed to
position the next web.
• Feed—feeds the labels to the first registration point.
To change the value shown:
1. Press SELECT to select the parameter.
2. Press
PLUS (+) or MINUS (-) to scroll through the options.
3. Press
SELECT to accept any changes and deselect the parameter.
Select Head Close Option
This parameter sets the action of the media when you close the printhead.
Default Value: CALIBRATION
Selections: CALIBRATION, SHORT CAL, LENGTH, NO MOTION,
FEED
• Calibration adjusts sensor levels and thresholds, determines length,
and feeds the media to the next web.
• Short Cal sets media and web thresholds without adjusting sensor
gain, determines length, and feeds the media to the next web.
• Length determines label length using current sensor values, and feeds
the media to the next web.
• No Motion tells the printer not to move the media. You must
manually ensure that the web is positioned correctly, or press feed to
position the next web.
• Feed—feeds the labels to the first registration point.
To change the value shown:
1. Press SELECT to select the parameter.
2. Press
PLUS (+) or MINUS (-) to scroll through the options.
3. Press
SELECT to accept any changes and deselect the parameter.
Table 12 • Printer Parameters (Page 19 of 24)
Parameter
Action/Explanation

Zebra ZM400 Series Specifications

General

Max Print Width	4.09 inches (104 mm)
Max Print Speed	10 inches per second (254 mm per second)
Print Method	Thermal Transfer/Direct Thermal
Resolution	203 dpi (8 dots/mm)
Connectivity	USB 2.0, Serial RS-232, Parallel, Internal Ethernet (10/100), optional wireless
Media Width	1"/25.4 mm to 4.5"/114 mm
Media Length	0.25 to 39 inches (6 to 991 mm)
Media Thickness	0.0023"/0.058 mm to 0.010"/0.25 mm
Ribbon Width	1"/25.4 mm to 4.33"/110 mm
Ribbon Length	1476 feet (450 m)
Supported Media Types	Continuous, die-cut, notch, black-mark
Operating Temperature	40°F to 105°F (5°C to 40°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
