ADCMT 6241A User Manual

6241A/6242 DC Voltage Current Source/Monitor Operation Manual
8.2.5 Calibrating Operation
8-23
Figure 8-13 6242 Calibration Procedure (6)
IM mode
Current-measurement
calibration
(30 µA to 300 mA range)
[Setting range]
Acquire
DMM data.
Execute the DMM data input.
XD DMM data
Readout the
measurement
data.
XD DMM data
Input DMM data.
ex. “XD-2.0e-6”
Store and display
calibration result data.
Acquire
DMM data.
Input DMM data.
ex. “XD3003.0e-6”
Readout the
measurement
data.
Store and display
calibration result data.
Within
tolerance?
