6241A/6242 DC Voltage Current Source/Monitor Operation Manual
2.2.3 Menu Operation
2-32
1) OPR Signal INTERLOCK/OPERATE IN/OUT control signal function
setting
STBY In/IntrLock In/Operate Out/OPR/SUS In
OPR/STBY In
Select
2) Cmpl/Sync COMPLETE OUT/SYNC OUT control signal function set-
ting
Meas Front/Meas End/Comp HI/Comp GO/Comp LO/Comp
HIorLO/Sync Out
Select
3) Sig Width Select control output pulse width
10 μs / 100 s
Select
(e)
Category level
Select level Input/Run level
K) PARAMETER
Parameter
types
1) Parm Load Loads the save parameters.
Select Load0/Load1/Load2/Load3/LdDflt and press
[ENTER] key to run.
Run
2) Parm Save Saves the setting parameters.
Select Save0/Save1/Save2/Save3/SvDflt and press [ENTER]
key to run.
Run
3) PON. Load Select Load Parameters at power on.
P.OFF / Load0
Select
(d)
L) I/F
1) I/F BUS Select interface.
GPIB/USB
Select
2) GPIB Adr GPIB Address When GPIB is selected
0 to 30
Numeric
2) USB Id USB Id When USB is selected
1 to 127
Numeric
3) Header Header
On/Off
Select
4) Talk Only Addressable/Talk only When GPIB is selected
Off/On
Select
J) EXT SIGNAL
