Configuring the display
Once you select both an instrument mode and appropriate measurement data,
configuring the display lets you specify how you want to look at the selected
measurement data.
Display format
You can use the analyzer’s [
Disp Format
] menu to view measurement data in the
following formats:
• single
• upper/lower
• front/back
• upper/big lower
• quad
• measurement state
• Bode diagram
Not all display formats are appropriate for all instrument modes. Those
formats that are inappropriate for a particular mode are unavailable when that
instrument mode is active.
In addition, you can reduce the amount of information on the screen if you use
the following display format features:
• grid on off
• blank annotation
• blank display
• trace title
• default title on/off
Agilent 35670A
Operator's Guide Setting Up a Measurement
Part I-17
