Agilent Technologies EXA N9010A User Manual

104
Compatible SCPI Commands
Supported SCPI Commands
This mode supports the following unit parameters: DBM | DBUV | DBMV | DBUA | V | A | W.
The query returns the current unit selection.
dBm
Sets the unit for the selected amplitude scale (log/lin) to dBm.
dBmV
Sets the unit for the selected amplitude scale (log/lin) to dBmV.
W
Sets the unit for the selected amplitude scale (log/lin) to Watt.
V
Sets the unit for the selected amplitude scale (log/lin) to Volt.
A
Sets the unit for the selected amplitude scale (log/lin) to Ampere.
Remote Command :CALCulate[1]:UNIT:POWer DBM|DBUV|DBMV|DBUA|V|A|W
:CALCulate[1]:UNIT:POWer?
Example CALC:UNIT:POW DBM
Remote Command Notes FSE, FSP, FSU
Preset DBM
State Saved Saved in instrument state.
Range DBM | DBUV | DBMV | DBUA | V | A | W
Backward Compatibility UNIT[1]|2:POWer
Remote Command Example: UNIT:POW DBM
Remote Command Example: UNIT:POW DBMV
Remote Command Example: UNIT:POW W
Remote Command Example: UNIT:POW V
Remote Command Example: UNIT:POW A
