161
Compatible SCPI Commands
Supported SCPI Commands
type>,<rbw>,<sample rate>,<trigger source>,<trigger slope>,<pretrigger samples>,<# of samples>.
TRACe<1|2>:IQ:SET <filter type>,<rbw>,<sample rate>,<trigger source>,<trigger
slope>,<pretrigger samples>,<# of samples>
Specifies the analyzer settings for measurement of I/Q data.
TRACe:IQ:SRATe 15.625kHz to 32MHz
Specifies the sampling rate for I/Q data acquisition.
TRACe:IQ:STATe ON | OFF
Switches the current measurement between SWEEP mode and I/Q mode.
Remote Command :TRACe[1]:IQ:DATA?
Example TRAC:IQ:DATA?
Remote Command Notes FSP, FSU
Remote Command TRACe[1]:IQ:SET <filter type>,<rbw>,<sample
rate>,<trigger source>,<trigger slope>,<pretrigger
samples>,<# of samples>
Example TRAC:IQ:SET NORM,10MHz,32MHz,EXT,POS,0,2048
TRAC:IQ:SET NORM,1MHz,4MHz,EXT,POS,1024,512
Remote Command Notes FSP, FSU
Remote Command TRACe[1]:IQ:SRATe <freq>
TRACe[1]:IQ:SRATe?
Example TRAC:IQ:SRAT 4MHZ
TRAC:IQ:SRAT?
Remote Command Notes FSP, FSU
Preset 32MHz
State Saved Saved in instrument state.
Min 15.625kHz
Max 32MHz
Remote Command :TRACe:IQ:STATe ON|OFF|1|0
:TRACe:IQ:STATe?
Example TRAC:IQ:STAT ON
Remote Command Notes FSP, FSU
