Compatible SCPI Commands
Supported SCPI Commands
CALCulate:MARKer Subsystem
The CALCulate:MARKer subsystem controls marker functions in the instrument.
NOTE All marker functions are not supported in the CCDF and APD measurements.
CALCulate<1|2>:MARKer<1...4>[:STATe] ON | OFF
The command switches the specified marker on or off.
If no numeric suffix is supplied, marker 1 is selected automatically.
If marker 2, 3 or 4 is selected and used as a delta marker, it is switched to marker mode.
The query returns the current state of this setting.
CALCulate<1|2>:MARKer<1...4>:AOFF
Turns off all active markers.
All delta markers are turned off.
All active marker and delta marker measurement functions are turned off.
CALCulate<1|2>:MARKer<1...4>:TRACe 1 to 3
The command assigns the specified marker to the trace defined by the command parameter.
If required, the corresponding marker is turned on.
The query returns the current assignment.
Remote Command :CALCulate[1]:MARKer[1]|2|3|4:STATe ON|OFF|1|0
:CALCulate[1]:MARKer[1]|2|3|4:STATe?
Example CALC:MARK3:STAT ON
Remote Command Notes FSE, FSP, FSU
Preset OFF
State Saved Saved in instrument state.
Remote Command :CALCulate[1]:MARKer[1]|2|3|4:AOFF
Example CALC:MARK:AOFF
Remote Command Notes FSE, FSP, FSU
Remote Command :CALCulate[1]:MARKer[1]|2|3|4:TRACe 1|2|3
:CALCulate[1]:MARKer[1]|2|3|4:TRACe?
Example CALC:MARK:TRAC 2
