92
Compatible SCPI Commands
Supported SCPI Commands
CALCulate<1|2>:MARKer<1...4>:MINimum[:PEAK]
Places the delta marker at the current maximum on the trace.
If required, the corresponding delta marker is first activated.
This command is an event, and therefore has no *RST value and no query.
CALCulate<1|2>:MARKer<1...4>:MINimum:NEXT
Places the marker at the next smaller maximum of the corresponding trace.
CALCulate<1|2>:MARKer<1...4>:MINimum:RIGHt
Places the delta marker at the next smaller maximum to the right of the current value (that is, in order of
increasing X values).
If required, the corresponding delta marker is first activated.
This command is an event, and therefore has no *RST value and no query.
CALCulate<1|2>:MARKer<1...4>:MINimum:LEFT
Places the marker at the next smaller maximum to the left of the current value (that is, in order of
decreasing X values) on the trace.
CALCulate<1|2>:MARKer<1...4>:PEXCursion <numeric_value>
The command specifies the peak excursion.
This mode supports only dB units.
Remote Command :CALCulate[1]:MARKer[1]|2|3|4:MINimum [:PEAK]
Example CALC:MARK:MIN
Remote Command Notes FSE, FSP, FSU
Remote Command :CALCulate[1]:MARKer[1]|2|3|4:MINimum:NEXT
Example CALC:MARK:MIN:NEXT
Remote Command Notes FSE, FSP, FSU
Remote Command CALCulate[1]:MARKer[1]|2|3|4:MAXimum:RIGHt
Example CALC:MARK:MAX:RIGH
Remote Command Notes FSE, FSP, FSU
Remote Command :CALCulate[1]:MARKer[1]|2|3|4:MINimum:LEFT
Example CALC:MARK:MIN:LEFT
Remote Command Notes FSE, FSP, FSU
