84
Compatible SCPI Commands
Supported SCPI Commands
CALCulate<1|2>:LIMit<1...6>:UPPer:MARGin <numeric_value>
The command defines a margin for the specified upper limit line. At the margin level, out-of-limit values
are signaled (if the limit check is active), but are not treated as violations of the limit value.
This mode does not support any unit for this command.
The query returns the current value of this setting.
CALCulate<1|2>:LIMit<1...6>:UPPer:MODE RELative | ABSolute
The command switches between relative or absolute scaling for the Y-axis of the specified upper limit
line.
Selecting RELative causes the unit to be switched to dB.
The query returns the current state of this setting.
CALCulate<1|2>:LIMit<1...6>:UPPer:SHIFt <numeric_value>
The command shifts the specified limit line in the Y-direction by the specified amount.
Example CALC:LIM:UPP:OFFS 1
CALC:LIM:UPP:OFFS?
Remote Command Notes FSE, FSP, FSU
Preset 0
Remote Command :CALCulate[1]:LIMit[1]|2|3|4|5|6:UPPer:MARGin <real>
:CALCulate[1]:LIMit[1]|2|3|4|5|6:Upper:MARGin?
Example CALC:LIM:UPP:MARG 10
CALC:LIM:UPP:MARG?
Remote Command Notes FSE, FSP, FSU
Preset 0
Remote Command :CALCulate[1]:LIMit[1]|2|3|4|5|6:UPPer:MODE
RELative|ABSolute
:CALCulate[1]:LIMit[1]|2|3|4|5|6:UPPer:MODE?
Example CALC:LIM:UPP:MODE ABS
CALC:LIM:UPP:MODE?
Remote Command Notes FSE, FSP, FSU
Preset ABS
State Saved
Saved in instrument state.
Range RELative | ABSolute
