132
Compatible SCPI Commands
Supported SCPI Commands
[SENSe<1|2>:]BANDwidth|BWIDth[:RESolution]:TYPE NORMal | FFT | CFILter | RRC
Sets the resolution bandwidth filter type to "normal" analog, FIR in 1, 3, 10 steps, or FFT for bandwidths
less than 100 kHz.
[SENSe<1|2>:]BANDwidth|BWIDth:VIDeo 1Hz to 10MHz
Sets the instrument's video bandwidth to between10 Hz and 10 MHz in 1, 3, 10 steps.
In the SCPILC mode, the maximum video bandwidth is 50 MHz and not 10 MHz as in FSx.
Remote Command Notes FSE, FSP, FSU
Preset 0.02 with BAND:TYPE NORMal or RBW > 30 kHz
0.01 with BAND:TYPE FFT for RBW 30 kHz
State Saved Saved in instrument state.
Min 0.0001
Max 1
Backwards Compatibility SCPI :SENSe1:BANDwidth|BWIDth[:RESolution]:RATio
Remote Command [:SENSe]:BANDwidth|BWIDth[:RESolution]:TYPE
NORMal|FFT|CFILter | RRC
[:SENSe]:BANDwidth|BWIDth[:RESolution]:TYPE?
Example BAND:TYPE RRC
BAND:TYPE?
Remote Command Notes FSP, FSU
Preset NORMal
State Saved Saved in instrument state.
Range NORMal | FFT | CFILter | RRC
Backwards Compatibility SCPI :SENSe1:BANDwidth|BWIDth[:RESolution]:TYPE
Remote Command [:SENSe]:BANDwidth|BWIDth:VIDeo <freq>
[:SENSe]:BANDwidth|BWIDth:VIDeo?
Example BAND:VID 1KHZ
BAND:VID?
Remote Command Notes FSE, FSP, FSU
Couplings
Preset 10 MHz
State Saved Saved in instrument state.
