Compatible SCPI Commands
Supported SCPI Commands
DISPlay[:WINDow<1|2>]:TRACe<1 to 3>:Y[:SCALe]:PDIVision
The command specifies the scaling of the Y-axis, using the currently-selected unit.
This mode supports only dB units.
The query returns the current value of this setting.
DISPlay[:WINDow<1|2>]:TRACe<1 to 3>:Y:SPACing LINear | LOGarithmic| LDB
The command switches between linear and logarithmic display.
This mode does not support the parameter option LDB.
The query returns the current state of this setting.
Remote Command Notes FSE, FSP, FSU
Preset 0 dB
State Saved Saved in instrument state.
Min –200.0 dB
Max 200 dB
Backwards Compatibility SCPI :DISPlay:TRACe[1]|2|3:Y[:SCALe]:RLEVel:OFFSet
Remote Command DISPlay:WINDow[1]:TRACe<1 to 3>:Y[:SCALe]:PDIVision
<rel_ampl>
DISPlay:WINDow[1]:TRACe<1 to 3>:Y[:SCALe]:PDIVision?
Example DISP:WIND:TRAC:Y:PDIV 5
DISP:WIND:TRAC:Y:PDIV?
Remote Command Notes FSE, FSP, FSU
State Saved Saved in instrument state.
Backwards Compatibility SCPI :DISPlay[1]:TRACe[1]|2|3:Y[:SCALe]:PDIVision
Remote Command :DISPlay:WINDow[1]:TRACe[1]|2|3:Y:SPACing
LINear|LOGarithmic
:DISPlay:WINDow[1]:TRACe[1]|2|3:Y:SPACing?
Example DISP:WIND:TRAC:Y:SPAC LOG
DISP:WIND:TRAC:Y:SPAC?
Remote Command Notes FSE, FSP, FSU
Preset LOG
State Saved Saved in instrument state.
Backwards Compatibility SCPI :DISPlay[1]:TRACe[1]|2|3:Y:SPACing
