29
Front Panel Operations
Selecting SCPI Language Compatibility Mode as the Power-on Application
Selecting SCPI Language Compatibility Mode as the
Power-on Application
NOTE Option N9062A-2FP or W9062A-2FP is required to use the SCPI Language
Compatibility mode.
To select the SCPI Language Compatibility mode as the power-on application, press the
System
hardkey on the X-Series analyzer front panel and then select the
Power On, SCPILC. If there are more
than six modes on the signal analyzer, then use the More button to find the
SCPILC mode selection.
Figure 2-2 is an example showing the power-on application setup.
Figure 2-2 Example Power On Mode Menu Map for X-Series Analyzers
To Next Page
