66
Compatible SCPI Commands
Supported SCPI Commands
CALCulate<1|2>:DELTamarker<1...4>:FUNCtion:FIXed:RPOint:X <numeric_value>
Sets or queries the reference frequency or time for all delta markers when you are making measurements
using a fixed reference value (enabled by CALCulate:DELTamarker:FUNCtion:FIXed:STATe ON).
For phase-noise measurements (selected via CALCulate:DELTamarker:FUNCtion:PNOise:STATe ON),
specifies a reference frequency or time for delta marker 2.
CALCulate<1|2>:DELTamarker<1...4>:FUNCtion:PNOise[:STATe] ON|OFF
The command switches phase-noise measurement on or off for all active delta markers. All correction
values are included.
If required, marker 1 is activated, and a peak search is performed. If marker 1 is activated, its position
becomes the measurementâs reference point.
The measurementâs reference point can be modified with commands
CALCulate:DELTamarker:FUNCtion:FIXed:RPOint:X and ...:RPOint:Y, independently of the position
of marker 1 and of any trace.
The DELTamarker numeric suffix <1 to 4> is not required for this command.
The query returns the current state of this setting.
CALCulate<1|2>:DELTamarker<1...4>:FUNCtion:PNOise:AUTO ON | OFF
The command switches on or off automatic peak search action for fixed reference marker 1. When
activated, this search occurs at the end of each sweep.
Preset 0
Remote Command :CALCulate[1]:DELTamarker[1]|2|3|4:FUNCtion:FIXed:RPOin
t:X <real>
:CALCulate[1]:DELTamarker[1]|2|3|4:FUNCtion:FIXed:RPOin
t:X?
Example CALC:DELT2:FUNC:FIX:RPO:X 10MHz
CALC1:DELT:FUNC:FIX:RPO:X?
Remote Command Notes FSE, FSP, FSU
Remote Command :CALCulate[1]:DELTamarker[1]|2|3|4:FUNCtion:PNOise[:STA
Te] ON|OFF|1|0
:CALCulate[1]:DELTamarker[1]|2|3|4:FUNCtion:PNOise[:STA
Te]?
Example CALC:DELT:FUNC:PNO ON
Remote Command Notes FSE, FSP, FSU
Preset OFF
State Saved Saved in instrument state.
