76
Compatible SCPI Commands
Supported SCPI Commands
CALCulate<1|2>:LIMit<1âĻ6>:ACPower:ALTernate<1|2>:ABSolute
Specifies the absolute limit value for the lower/upper alternate adjacent channel power measurement
(Adjacent Channel Power) in the selected measurement window.
The numeric suffix after ALTernate<1|2> denotes the first or the second alternate channel. The numeric
suffixes <1 to 6> are irrelevant for this command.
CALCulate<1|2>:LIMit<1âĻ6>:ACPower:ALTernate<1|2>:ABSolute:STATe
Specifies the limit check for the first/second alternate adjacent channel in the selected measurement
window for ACP measurement.
Before the command, the limit check must be globally switched on for the channel/adjacent channel
power with the command CALCulate:LIMit:ACPower:STATe ON.
The numeric suffix after ALTernate<1|2> denotes the first or the second alternate channel. The numeric
suffixes <1 to 6> are irrelevant for this command.
The result can be queried with CALCulate:LIMit:ACPower:ALTernate<1|2>:RESult?. A complete
measurement must be performed between switching on the limit check and the result query, since
otherwise no valid results are available.
State Saved Saved in instrument state.
Remote Command :CALCulate[1]:LIMit[1]|2|3|4|5|6:ACPower:ALTernate[1]|2
:ABSolute <real>,<real>
:CALCulate[1]:LIMit[1]|2|3|4|5|6:ACPower:ALTernate[1]|2
:ABSolute?
Example CALC:LIM:ACP:ALT:ABS 30DBM, 30DBM
CALC:LIM:ACP:ALT:ABS?
Notes FSU, FSP, FSE
Preset â200dBm, â200dBm
State Saved Saved in instrument state.
Remote Command :CALCulate[1]:LIMit[1]|2|3|4|5|6:ACPower:ALTernate[1]|2
:ABSolute:STATe ON|OFF|1|0
:CALCulate[1]:LIMit[1]|2|3|4|5|6:ACPower:ALTernate[1]|2
:ABSolute:STATe?
Example CALC:LIM:ACP:ALT:ABS:STAT ON
CALC:LIM:ACP:ALT:ABS:STAT?
Notes FSU, FSP, FSE
Preset OFF
State Saved Saved in instrument state.
