11 3
Compatible SCPI Commands
Supported SCPI Commands
DISPlay[:WINDow<1|2>]:TRACe<1âĻ3>:MODE WRITe | VIEW | AVERage | MAXHold |
MINHold
The command specifies the display type and evaluation mode for the specified trace.
The query returns the current state of this setting for the specified trace.
DISPlay[:WINDow<1|2>]:TRACe<1 to 3>[:STATe] ON | OFF
The command switches on or off display of the corresponding trace.
The query returns the current state of this setting.
FORMat Subsystem
The FORMat subsystem specifies the format of data transmitted from and received by the instrument.
FORMat[:DATA]
The command specifies the format for data transmitted from the instrument to a control PC.
This command is specific to X-Series analyzers.
Remote Command :DISPlay:WINDow[1]:TRACe[1]|2|3:MODE
WRITe|VIEW|AVERage|MAXHold|MINHold
:DISPlay:WINDow[1]:TRACe[1]|2|3:MODE?
Example DISP:WIND1:TRAC:MODE WRIT
Remote Command Notes FSE, FSP, FSU
Preset WRITe
State Saved Saved in instrument state.
Range WRITe | VIEW | AVERage | MAXHold | MINHold
Backwards Compatibility SCPI :DISPlay:TRACe[1]|2|3:MODE
Remote Command :DISPlay[1]:WINDow[1]:TRACe[1]|2|3[:STATe] ON|OFF|1|0
:DISPlay[1]:WINDow[1]:TRACe[1]|2|3[:STATe]?
Example DISP:TRAC1 ON
Remote Command Notes FSE, FSP, FSU
Preset ON for Trace 1, OFF for the others
State Saved Saved in instrument state.
Backwards Compatibility SCPI :DISPlay[1]:TRACe[1]|2|3[:STATe]
