2. General info
2.1 Location of modules
Convention - Projector orientation
Front
Light processor side
L
a
m
p
s
i
d
e
o
r
I
n
p
u
t
s
i
d
e
Rear
Image 2-1
Projector orientation
Rear side and Lamp side
B
A
C ED
F
Image 2-2
Reference
Description
A IR receiver
B
Lamp power supply unit (LPS) unit
C
Lamp unit
D
Cathode fan assembly
E
Input & communication unit
F Backlight unit
