13. Cold mirror assembly

13.3 Mounting the new cold mirror + fan assembly

WARNING: This procedure may only be performed by qualified technical service personnel.

Necessary tools

•Allenkey3mm

• Flat screwdriver 7 mm

How to mount

1. Insert the assembly in the projector and make the electrical connection of the fan.

Image 13-6

Insert assembly + electrical connection

2. At the left side of the cold mirror assembly, turn in both indicated screws 1.

124

R59770072 FLM SERIES 19/03/2007
