29. Convergence adjustment
29. CONVERGENCE ADJUSTMENT
About this chapter
This chapter gives the procedures to re-convergence Green on Blue and Red on Blue when a small convergence drift is recognized.
This will limit the return of the light processor to the factory.
As the blue DMD is not accessible in the projector, the image of this DMD will be taken as reference.
Order information Re-convergence toolkit
Order number
Description
R8471961K FLM Re-convergence toolkit
Overview
• Action of the convergence controls
• Re-converging Green on Blue
• Readjustment of the plungers
• Re-converging Red on Blue
Relevant test pattern
Press the Lens button on the remote control or the local keypad to display the lens menu. Toggle with this button until the relevant
convergence pattern is displayed. The following 2 test patterns are relevant to re-convergence Green on Red DMD and Red on the
Blue DMD (Blue=reference).
R59770072 FLM SERIES 19/03/2007
313
