26. Power input

26.1 Getting access to the power elements

Remove the back cover and the lamp cover.

Necessary tools

Allen key 3mm

How to get access

1. Unplug the fan connection.

Image 26-3

Fan connection

2. Just loosen the 9 indicated screws. Do not turn them out.

Image 26-4

Shield

3. Move the shield plate to the left a

nd take out the plate.

288

R59770072 FLM SERIES 19/03/2007
