4. About lenses
4.2 Lens selection
How to select the right lens for your application ?
1. Determine the required screen width (SW).
2. Determine the position of the projector in the projection room with regard to the screen and measure the projector-screen distance
(PD).
3. Use the lens formulas to find the best corresponding PD with regard to the measured projector-screen distance for the required
screen width SW.
Tip: Divide PD by SW to determine the approximately required throw ratio. Choose a lens, which captures the calculated
throw ratio. Use the lens formula of the chosen lens to recalculate exactly.
SCREEN
PD
SW
Image 4-8
R59770072 FLM SERIES 19/03/2007 61
