7. Dust filters
7.3 Replacement of the dust filter on the top side
Necessary parts
New HEPA dust filter for the top side (R9854480).
How to replace the HEPA dust filter on the top side of the projector ?
1. Remove the side cover of the projector, see "Removal of the side cover", page 73.
2. Remove the filter (F) on the bottom side by pulling out the filter holder (H) as illustrated.
F
H
Image 7-6
3. Place a new HEPA dust filter in the filter holder.
4. Reinstall the filter holder containing the new HEPA filter.
5. Reinstall the side cover of the projector, see "Installation of the side cover", page 81.
CAUTION: Never install a used HEPA filter. Always install a new HEPA filter.
88 R59770072 FLM SERIES 19/03/2007
