22. LCD panel replacement
Image 22-6
Connection LCD - keypad
6. Remove the 4 fixation screws of the LCD panel.
Image 22-7
Remove LCD panel
7. Remove the defective LCD panel.
222
R59770072 FLM SERIES 19/03/2007
