24. Fan replacements

Image 24-28 Image 24-29

4. Turn out the 3 screws of the side plate of the air channel and take the plate away. Cut the foam rubber as it is stuck on the

different plates.

Image 24-30

Side plate air channel

5. Turn out the 4 screws holding the fan assembly to the frame and cut the foam rubber.

R59770072 FLM SERIES 19/03/2007

251
