BONFIGLIOLI Agile User Manual

Parameter list
Actual value parameter
No.
Description
Unit
Display range
Chapter
244
Working Hours Counter
h
99999
9.1
245
Operation Hours Counter
h
99999
9.1
246 Capacitor Temperature deg.C 0 ... T
emax
9.1
249
Active Data Set
-
1 ... 4
9.1
250
Digital Inputs
-
00 ... 255
9.1
251 Analog Input MFI1A %
± 100.00
9.1
252
Repetition Frequency Input
Hz
0.0 ... 999.99
9.1
253
Analog Input MFI2A
%
±
100.00
9.1
254 Digital Outputs - 00 ... 255
9.1
255
Heat Sink Temperature
deg.C
0 ... T
kmax
9.1
256
Inside Temperature
deg.C
0 ... T
imax
9.1
257 Analog Output MFO1A V 0.0 ... 24.0
9.1
258
PWM-Input
%
0.00 … 100.00
9.1
259
Actual error
-
FXXXX
9.1
260 Actual error - 0 ... 0xFFFF CM
269
Warnings
-
AXXXX
9.1
270 Warnings - 0 ... 0xFFFF (bit-coded) CM
273 Application Warnings - AXXXX
9.1
274
Application Warnings
-
0 ... 0xFFFF (bit-coded)
CM
275 Controller Status - CXXXX
9.1
277
STO Status
-
XXXX
9.1
278
Frequency MFO1F
Hz
0.00 ... f
max
9.1
282 Reference Bus Frequency Hz -1000.00 … 1000.00
9.1
283
Reference Ramp Frequency
Hz
0.00 ... 999.99
9.1
Note:
The parameters
Current error 260, Warnings 270 and Application Warnings 270 are only accessi-
ble Fieldbus. They cannot be accessed via the VPlus PC-Software or the Operator Panel.
No.
Description
Unit
Display range
Chapter
Actual value memory
287
Peak Value Vdc
V
0.0 ... U
dmax
9.4
288 Average Value Vdc V 0.0 ... U
dmax
9.4
289
Peak Value Heat Sink Temp.
deg.C
0 ... T
kmax
9.4
290 Average Value Heat Sink Temp. deg.C 0 ... T
kmax
9.4
291 Peak Value Inside Temperature deg.C 0 ... T
imax
9.4
292
Average Value Inside Temperature
deg.C
0 ... T
imax
9.4
293 Peak Value Iabs. A 0.0 ... o
c
⋅I
FIN
9.4
294
Average Value Iabs
A
0.0 ... o
c
⋅I
FIN
9.4
295
Peak Value Active Power pos.
kW
0.0 ... o
c
⋅P
FIN
9.4
296 Peak Value Active Power neg. kW
0.0 ... o
c
⋅P
FIN
9.4
297
Average Value Active Power
kW
0.0 ... o
c
⋅P
FIN
9.4
298
Peak Value Capacitor Temp.
deg.C
0 ... T
emax
9.4
299 Average Value Capacitor Temp. deg.C 0 ... T
emax
9.4
301
Energy positive
kWh
0 ... 99999
9.4
302
Energy negative
kWh
0 ... 99999
9.4
Error list
310 Last error h:m; F 00000:00; FXXXX
13.1
311 Last Error but one h:m; F 00000:00; FXXXX
13.1
340
Operating Instructions
Agile 06/2013 Actual values (Menu Actual)
