BONFIGLIOLI Agile User Manual

Parameter list
No.
Description
Unit
Display range
Chapter
312 Error 3 h:m; F 00000:00; FXXXX
13.1
313
Error 4
h:m; F
00000:00; FXXXX
13.1
314 Error 5 h:m; F 00000:00; FXXXX
13.1
315
Error 6
h:m; F
00000:00; FXXXX
13.1
316
Error 7
h:m; F
00000:00; FXXXX
13.1
317 Error 8 h:m; F 00000:00; FXXXX
13.1
318
Error 9
h:m; F
00000:00; FXXXX
13.1
319
Error 10
h:m; F
00000:00; FXXXX
13.1
320 Error 11 h:m; F 00000:00; FXXXX
13.1
321
Error 12
h:m; F
00000:00; FXXXX
13.1
322
Error 13
h:m; F
00000:00; FXXXX
13.1
323
Error 14
h:m; F
00000:00; FXXXX
13.1
324 Error 15 h:m; F 00000:00; FXXXX
13.1
325 Error 16 h:m; F 00000:00; FXXXX
13.1
Error environment
330
DC-Link Voltage
V
0.0 ... U
dmax
13.2
331
Output Voltage
V
0.0 ... U
FIN
13.2
332 Stator Frequency Hz 0.00 ... 999.99
13.2
335 Phase current Ia A 0.0 ... I
max
13.2
336 Phase current Ib A 0.0 ... I
max
13.2
337 Phase current Ic A 0.0 ... I
max
13.2
338
rms Current
A
0.0 ... I
max
13.2
339
Isd / Reactive Current
A
0.0 ... I
max
13.2
340
Isq / Active Current
A
0.0 ... I
max
13.2
341
Rotor Magnetizing Current
A
0.0 ... I
max
13.2
342
Torque
Nm
±
9999.9
13.2
343
Analog Input MFI1A
%
±
100.00
13.2
344 Analog Input MFI2A % ± 100.00
13.2
346 Analog Output MFO1A V 0.0 ... 24.0
13.2
348 DC-link Cap. Temperature deg.C 0 ... T
emax
13.2
349 Repetition Frequency Output Hz 0.00 ... 999.99
13.2
350 Status of Digital Inputs - 00 ... 255
14.1
351
Status of Digital Outputs
-
00 ... 255
14.1
352
Time since Release
h:m:s.ms
00000:00:00.000
13.2
353
Heat Sink Temperature
deg.C
0 ... T
kmax
13.2
354
Inside Temperature
deg.C
0 ... T
imax
13.2
355
Controller Status
-
C0000 ... CFFFF
13.2
356 Warning Status - A0000 ... AFFFF
14.3
357 Int. Value 1 - ± 32768
13.2
358 Int. Value 2 - ± 32768
13.2
359 Long Value 1 - ± 2147483647
13.2
360
Long Value 2
-
± 2147483647
13.2
361
Checksum
-
OK / NOK
13.2
Error list
362 No. of Errors - 0 ... 32767
13.1
363 No. of self acknowledged Errors - 0 ... 32767
13.1
Error environment
367
Application Warning State
-
A0000 … AFFFF
14.3
