Parameter list
Parameters
No.
Description
Unit
Setting range
Chapter
Motor potentiometer
473
Ramp Frequency-Motorpoti
Hz/s
0.01 ... 999.99
7.5.3.3.1
474
Operation Mode
-
Selection
7.5.3
Frequency reference channel
475
Reference Frequency Source 1
-
Selection
7.5.1
Reference percentage channel
476
Reference Percentage Source 1
-
Selection
7.5.2
Ref. perc. val. channel/ramp
477 Gradient Percentage Ramp %/s 0 ... 60000
7.5.2.4
PID controller (technology controller)
478
Actual Percentage Source
-
Selection
7.9.3
Fixed frequencies
480
Fixed Frequency 1
Hz
-999.99 ... 999.99
7.5.1.3
481
Fixed Frequency 2
Hz
-999.99 ... 999.99
7.5.1.3
482 Fixed Frequency 3 Hz -999.99 ... 999.99
7.5.1.3
483 Fixed Frequency 4 Hz -999.99 ... 999.99
7.5.1.3
484 Reference Frequency RAM Hz -999.99 … 999.99 CM
485
Fixed Frequency 5
Hz
-999.99 ... 999.99
7.5.1.3
486
Fixed Frequency 6
Hz
-999.99 ... 999.99
7.5.1.3
487
Fixed Frequency 7
Hz
-999.99 ... 999.99
7.5.1.3
488
Fixed Frequency 8
Hz
-999.99 ... 999.99
7.5.1.3
489
JOG Frequency
Hz
-999.99 ... 999.99
7.5.1.6
Frequency reference channel
492
Reference Frequency Source 2
-
Selection
7.5.1
493
Operation Mode
-
Selection
7.5.1.2
Reference percentage channel
494
Reference Percentage Source 2
-
Selection
7.5.2
495
Operation Mode
-
Selection
7.5.2.2
PWM input/repetition frequency input/pulse train
496
Operation mode IN2D
-
Selection
7.6.7
Repetition frequency input
497
Rep.Freq. : Divider
-
1 ... 8192
7.6.7.2
Brake Chopper
506 Trigger Threshold V
AGL202: 225.0 … 1000.0
AGL402: 325.0 … 1000.0
7.10.4
Motor chopper
507
Trigger Threshold V
AGL202: 225.0 … 1000.0
AGL402: 325.0 … 1000.0
7.10.5
Motor potentiometer
509
Ramp Percentage-Motorpoti
%/s
0.00 … 600.00
7.5.3.3.2
Digital outputs
510 Setting Frequency Hz 0.00 ... 999.99
7.6.5.2
517
Setting Frequency Switch Off Del-
ta
Hz 0.00 … 999.99
7.6.5.2
Percentage value limits
518 Minimum Reference Percentage % 0.00 ... 300.00
7.5.2.1
519 Maximum Reference Percentage % 0.00 ... 300.00
7.5.2.1
Fixed percentages
520 Fixed Percentage 1 % -300.00 ... 300.00
7.5.2.3
521 Fixed Percentage 2 % -300.00 ... 300.00
7.5.2.3
522 Fixed Percentage 3 % -300.00 ... 300.00
7.5.2.3
523
Fixed Percentage 4
%
-300.00 ... 300.00
7.5.2.3
524
Reference Percentage RAM
%
-300.00 ... 300.00
CM
346
Operating Instructions
Agile 06/2013 Parameters (Menu PARA)
