BONFIGLIOLI Agile User Manual

Parameter list
Parameters
No.
Description
Unit
Setting range
Chapter
Error/warning behavior
417
Frequency Switch-off Limit
Hz
0.00 ... 999.99
7.4.4
Frequency Limits
418 Minimum Frequency Hz 0.00 ... 999.99
7.5.1.1
419 Maximum Frequency Hz 0.00 ... 999.99
7.5.1.1
Frequency ramps
420 Acceleration (Clockwise) Hz/s 0.00 ... 9999.99
7.5.1.4
421 Deceleration (Clockwise) Hz/s -0.01 ... 9999.99
7.5.1.4
422 Acceleration Anticlockwise Hz/s -0.01 ... 9999.99
7.5.1.4
423
Deceleration Anticlockwise
Hz/s
-0.01 ... 9999.99
7.5.1.4
424
Emergency Stop Clockwise
Hz/s
0.01 ... 9999.99
7.5.1.4
425
Emergency Stop Anticlockwise
Hz/s
0.01 ... 9999.99
7.5.1.4
426
Maximum Leading
Hz
0.01 ... 999.99
7.5.1.4
430 Ramp Rise Time ms 0 ... 10000
7.5.1.4
Traverse function
435
Operation Mode
-
Selection
7.10.8
436
Ramp-up Time
s
0.01 … 320.00
7.10.8
437
Ramp-down Time
s
0.01 … 320.00
7.10.8
438 Traverse Amplitude % 0.01 … 50.00
7.10.8
439 Proportional Step % 0.01 … 50.00
7.10.8
PID controller (technology controller)
440
Operation Mode Actual Value Fail-
ure
- Selection
7.9.3
441 Max. I-component Hz 0.00 ... 999.99
7.9.3
442
Maximum Frequency
Hz
0.00 ... 999.99
7.9.3
443
Minimum Frequency
Hz
-999.99 … 0.00
7.9.3
444
Amplification
-
-15.00 ... 15.00
7.9.3
445
Integral Time
ms
0 ... 32767
7.9.3
446
Derivative Time
ms
0 … 1000
7.9.3
Reference frequency channel/blocking frequencies
447
1st Blocking Frequency
Hz
0.00 ... 999.99
7.5.1.5
448
2nd Blocking Frequency
Hz
0.00 ... 999.99
7.5.1.5
449
Frequency Hysteresis
Hz
0.00 ... 100.00
7.5.1.5
Multifunction input 1 (MFI1)
450
Tolerance Band
%
0.00 ... 25.00
7.6.1.1.2
451
Filter Time Constant
ms
Selection
7.6.1.1.3
452
Operation Mode MFI1
-
Selection
7.6.1
453
Error/Warning Behaviour
-
Selection
7.6.1.1.3
454
Characteristic Curve Point X1
%
0.00 ... 100.00
7.6.1.1.2
455 Characteristic Curve Point Y1 % -100.00 ... 100.00
7.6.1.1.2
456 Characteristic Curve Point X2 % 0.00 ... 100.00
7.6.1.1.2
457
Characteristic Curve Point Y2
%
-100.00 ... 100.00
7.6.1.1.2
Positioning
458
Operation Mode
-
Selection
7.3.7
459 Signal Source - Selection
7.3.7
460
Positioning Distance
U
0.000 ... 1 10
6
7.3.7
461
Signal Correction
ms
-327.68 ... 327.67
7.3.7
462
Load Correction
-
-32768 ... 32767
7.3.7
463
Activity after Positioning
-
Selection
7.3.7
464
Waiting Time
ms
0 ... 3.6 10
6
7.3.7
345
Parameters (Menu PARA) 06/2013 Operating Instructions
Agile
