BONFIGLIOLI Agile User Manual

Parameter list
Parameters
No.
Description
Unit
Setting range
Chapter
529 Actual Percentage RAM % -300.00 ... 300.00 CM
Digital outputs
531
Op. Mode OUT1D (X13.5)
-
Selection
7.6.5
532 Op. Mode OUT2D (X10/Relay) - Selection
7.6.5
533 Op. Mode OUT3D (X11.6) - Selection
7.6.5
Error/warning behavior
535 Op. Mode ext. Error - Selection
7.4.5
536 Create Warning Mask - Selection
7.6.5.8
Digital outputs
549
Reference Value Reached: Toler-
ance Band
% 0.01 ... 20.00
7.6.5.3
Multifunction output 1 (MFO1)
550 Operation Mode MFO1 (X13.6) - Selection
7.6.3
551
Analog: Voltage 100%
V
0.0 ... 22.0
7.6.3
552
Analog: Voltage 0%
V
0.0 ... 22.0
7.6.3
553
Analog: Source MFO1A
-
Selection
7.6.3
554
Digital: Source MFO1D
-
Selection
7.6.3
555
RF/PT: Output Value MFO1F
-
Selection
7.6.3
556 RF: Division Marks - 30 ... 8192
7.6.3
557 PT: Scaling Frequency - 0 … 32000
7.6.3
Digital input/output
558
Operation Mode Terminal X11.6
-
Selection
7.6.4
559
Digital Inputs PNP/NPN
-
Selection
7.6.6
Multifunction input 2 (MFI2)
560
Tolerance Band
%
0.00 … 25.00
7.6.2.1.2
561 Filter Time Constant - Selection
7.6.2.1.3
562
Operation Mode MFI2
-
Selection
7.6.2
563
Error/Warning Behaviour
-
Selection
7.6.2.1.3
564
Characteristic Curve Point X1
%
0.00 … 100.00
7.6.2.1.2
565
Characteristic Curve Point Y1
%
-100.00 … 100.00
7.6.2.1.2
566
Characteristic Curve Point X2
%
0.00 … 100.00
7.6.2.1.2
567 Characteristic Curve Point Y2 % -100.00 … 100.00
7.6.2.1.2
Error/warning behavior
570
Operation Mode Motor Temp.
-
Selection
7.4.6
Motor Protection
571 Operation Mode - Selection
7.10.6.1
572
Frequency Limit
%
0 ... 300
7.10.6.1
Intelligent current limits
573
Operation Mode
-
Selection
7.9.1
574 Power Limit % 40.00 ... 95.00
7.9.1
575 Limitation Time min 5 ... 300
7.9.1
Error/warning behavior
576
Phase Supervision
-
Selection
7.4.7
578
Allowed No. of Auto-Acknowl.
-
0 ... 20
7.4.8
579 Restart Delay ms 0 ... 1000
7.4.8
Pulse width modulation
580
Reduction Limit Ti/Tc
deg.C
-25 ... 0
7.10.1
V-belt monitoring
581 Operation Mode - Selection
7.10.7
582
Trigger Limit Iactive
%
0.1 ... 100.0
7.10.7
583
Delay Time
s
0.1 ... 600.0
7.10.7
347
Parameters (Menu PARA) 06/2013 Operating Instructions
