Parameter list
Parameters
No.
Description
Unit
Setting range
Chapter
V/f characteristic
600
Starting Voltage
V
0.0 ... 100.0
7.7
601
Voltage Rise
%
-100 ... 200
7.7
602
Rise Frequency
%
0 ... 100
7.7
603 Cut-Off Voltage V
AGL202: 30.0 ... 280.0
AGL402: 60.0 ... 560.0
7.7
604 Cut-Off Frequency Hz 0.00 ... 999.99
7.7
605
Dyn. Voltage Pre-Control
%
0 ... 200
7.8.1
606
Type V/f characteristic
-
Selection
7.7
I
2
t Monitoring
608 Thermal Time Constant Motor min 1 … 240 7.10.6.2
609 Thermal Time Constant Rotor s 1 … 600 7.10.6.2
Current limit value controller
610
Operation Mode
-
Selection
7.9.4.2
611 Amplification - 0.01 ... 30.00
7.9.4.2
612 Integral Time ms 1 ... 10000
7.9.4.2
613
Current Limit
A
0.0 ... o
c
⋅I
FIN
7.9.4.2
614
Frequency Limit
Hz
0.00 ... 999.99
7.9.4.2
I
2
t Monitoring
615 Warning Limit Motor I
2
t % 6 … 100 7.10.6.2
PID controller (technology controller)
616 Backlash Motor Power of - Selection
7.9.3
Error/warning behavior
617
Max. Temp. Motor Winding
°C
0 … 200
7.4.6
PID controller (technology controller)
618
Backlash
%
0.00 … 30.00
7.9.3
Starting behavior
620
Operation Mode
-
Selection
7.3.2
621
Amplification
-
0.01 ... 10.00
7.3.2
622
Integral Time
ms
1 ... 30000
7.3.2
623
Starting Current
A
0.0 ... o
c
⋅I
FIN
7.3.2
624
Frequency Limit
Hz
0.00 ... 100.00
7.3.2
625 Brake Release Time ms -5000 … 5000
7.3.2
Warning application
626
Create Appl. Warning Mask
-
Selection
7.6.5.9
Stopping behavior
630 Operation Mode - Selection
7.3.3
Direct current brake
631
Braking Current
A
0.00 ... √2⋅I
FIN
7.3.6
632 Braking Time s 0.0 ... 200.0
7.3.6
633 Demagnetizing Time s 0.1 ... 30.0
7.3.6
634
Amplification
-
0.00 ... 10.00
7.3.6
635
Integral Time
ms
0 ... 1000
7.3.6
Stopping behavior
637
Switch-Off Threshold Stop Func-
tion
% 0.0 ... 100.0
7.3.3
638
Holding Time Stop Function
s
0.0 ... 200.0
7.3.3
Flying Start
645
Operation Mode Flying Start
-
Selection
7.3.5
Auto start
651
Operation Mode
-
Selection
7.3.4
PWM input
652 PWM Offset % -100.00 … 100.00
7.6.7.1
348
Operating Instructions
Agile 06/2013 Parameters (Menu PARA)
