Parameter list
Parameters
No.
Description
Unit
Setting range
Chapter
653 PWM-Amplification % 5.0 … 1000.0
7.6.7.1
Pulse train
654
Pulse Train Scaling Frequency
-
0 … 32000
7.6.7.3
Slip compensation
660
Operation Mode
-
Selection
7.9.4.1
661
Amplification
%
0.0 ... 300.0
7.9.4.1
662
Max. Slip Ramp
Hz/s
0.01 ... 650.00
7.9.4.1
663
Frequency Lower Limit
Hz
0.01 ... 999.99
7.9.4.1
Voltage controller
670
Operation Mode
-
Selection
7.9.2
671
Mains Failure Threshold
V
-200.0 ... -50.0
7.9.2
672
Reference Mains Support Value
V
-200.0 ... -10.0
7.9.2
673
Mains Support Deceleration
Hz/s
0.01 ... 9999.99
7.9.2
674
Acceleration on Mains Resumption
Hz/s
0.00 ... 9999.99
7.9.2
675 Shutdown Threshold Hz 0.00 ... 999.99
7.9.2
676 Reference Shutdown Value V
AGL202: 225.0 … 387.5
AGL402: 325.0 … 775.0
7.9.2
677
Amplification
-
0.00 ... 30.00
7.9.2
678
Integral Time
ms
0 ... 10000
7.9.2
680 Reference DC-Link Limitation V
AGL202: 225.0 … 387.5
AGL402: 325.0 … 775.0
7.9.2
681
Max. Frequency Rise
Hz
0.00 ... 999.99
7.9.2
683 Gen. Ref. Current Limit A 0.0 ... o
c
⋅I
FIN
7.9.2
Electronic gear
685
Gear Factor Numerator
-
-300.00 ... 300.00
7.5.4.3.1
686
Gear Factor Denominator
-
0.01 ... 300.00
7.5.4.3.1
687 Analog factor at 100% - 0.00 ... 100.00
7.5.4.3.2
688 Analog factor at 0% - 0.00 ... 100.00
7.5.4.3.2
689 Operation Mode - Selection
7.5.4.2
Current controller
700
Amplification
-
0.00 ... 8.00
7.9.5.1
701 Integral Time ms 0.00 ... 10.00
7.9.5.1
Further motor parameters
716
Rated magnetising current
A
0.01⋅I
FIN
... o
c
⋅I
FIN
7.2.2
Field controller
717 Flux Reference Value % 0.01 ... 300.00
7.9.5.5
Further motor parameters
718
Rated Slip Correction Factor
%
0.01 ... 300.00
7.2.2
Frequency Limits
719
Slip Frequency
%
0 ... 10000
7.5.1.1
Speed controller
720
Operation Mode
-
Selection
7.9.5.3
721 Amplification 1(|f|<P738) - 0.00 ... 200.00
7.9.5.3
722 Integral Time 1(|f|<P738) ms 0 ... 60000
7.9.5.3
723
Amplification 2(|f|>P738)
-
0.00 ... 200.00
7.9.5.3
724
Integral Time 2(|f|>P738)
ms
0 ... 60000
7.9.5.3
Acceleration pre-control
725 Operation Mode - Selection
7.9.5.4
726 Minimum Acceleration Hz/s 0.1 ... 6500.0
7.9.5.4
727
Mech. Time Constant
ms
1 ... 60000
7.9.5.4
Speed controller
728
Current Limit
A
0.0 ... o
c
⋅I
FIN
7.9.5.3.1
729 Current Limit Generator Op. A -0.01 ... o
c
⋅I
FIN
7.9.5.3.1
349
Parameters (Menu PARA) 06/2013 Operating Instructions
