BONFIGLIOLI Agile User Manual

Parameter list
Parameters
No.
Description
Unit
Setting range
Chapter
730 Torque Limit % 0.00 ... 650.00
7.9.5.3.1
731
Torque Limit Generator Operation
%
0.00 ... 650.00
7.9.5.3.1
732
P-Comp. Torque Upper Limit
%
0.00 ... 650.00
7.9.5.3.1
733
P-Comp. Torque Lower Limit
%
0.00 ... 650.00
7.9.5.3.1
734
Isq Limit Source Motor Op.
-
Selection
7.9.5.3.2
735
Isq Limit Source Generator Op.
-
Selection
7.9.5.3.2
736 Torque Limit Source Motor Op. - Selection
7.9.5.3.2
737 Torque Limit Source Gen. Op. - Selection
7.9.5.3.2
738
Speed Control Switch-Over Limit
Hz
0.00 ... 999.99
7.9.5.3
739
Power Limit
kW
0.00 ... 2⋅ o
c
⋅P
FIN
7.9.5.3.1
740
Power Limit Generator Operation
kW
0.00 ... 2⋅ o
c
⋅P
FIN
7.9.5.3.1
Field controller
741
Amplification
-
0.0 ... 100.0
7.9.5.5
742
Integral Time
ms
0.0 ... 1000.0
7.9.5.5
743
Ref. Isd Upper Limit
A
0.0 … o
c
⋅I
FIN
7.9.5.5.1
744
Ref. Isd Lower Limit
A
-I
FIN
... I
FIN
7.9.5.5.1
Current controller
746
Cross-Coupling Factor
%
0.00 … 300.00
7.9.5.1
Speed controller
748
Backlash Damping
%
0 ... 300
7.9.5.3
Modulation controller
750
Reference Modulation
%
3.00 ... 105.00
7.9.5.6
752
Integral Time
ms
0.0 ... 1000.00
7.9.5.6
753
Operation Mode
-
Selection
7.9.5.6
755
Reference Imr Lower Limit
A
0.01⋅I
FIN
... o
c
⋅I
FIN
7.9.5.6.1
756 Control Deviation Limitation % 0.00 ... 100.00
7.9.5.6.1
Torque controller
767
Frequency Upper Limit Hz
-999.99 ...
999ohne.99
7.9.5.2
768
Frequency Lower Limit
Hz
-999.99 ... 999.99
7.9.5.2
769 Frequency upper limit source - Selection
7.9.5.2.3
770
Frequency lower limit source
-
Selection
7.9.5.2.3
Starting behavior
779
Min. Flux-Formation Time
ms
1 ... 10000
7.3.2
780 Max. Flux-Formation Time ms 1 ... 10000
7.3.2
781 Current during Flux-Formation A
0.1⋅I
FIN
... o
c
⋅I
FIN
7.3.2
Auto set-up
796
SETUP Selection
-
Selection
6.8
System bus
900 Node-ID - -1 ... 63
6.2.10.2
Systemb.
903 Baud-Rate - Selection
6.2.10.2
Systemb.
904
Boot-Up Delay
ms
3500 ... 50000
Systemb.
918
SYNC-Identifier
-
0 ... 2047
919
SYNC-Time
ms
0 ... 50000
921
RxSDO1-Identifier
-
0 ... 2047
922 TxSDO1-Identifier - 0 ... 2047
923 SDO2 Set Active - Selection
924
RxPDO1 Identifier
-
0 ... 2047
925
TxPDO1 Identifier
-
0 ... 2047
350
Operating Instructions
Agile 06/2013 Parameters (Menu PARA)
