Commissioning
Starting behaviour (field-oriented)
P30: 410 - IM: sensor-less field-oriented control"
P30: 610 - PMSM: sensor-less field-oriented control"
Starting Current (value: I
FIN
)
1
For sufficient torque if a high start torque is re-
quired. The start current is impressed until the
output frequency reaches the value of P624.
Frequency Limit (2.60 Hz)
The starting current is impressed up to this output frequency.
The current during flux-formation (P781) is impressed at least for this time.
Max. Flux-Formation Time (P30=410: 1000 ms), (P30=610: 50 ms)
The current during flux-formation (P781) is impressed not longer than this time.
Current during flux-formation (value: I
FIN
)
Upon startup, this current value is impressed. The time for current impression is limited
by P780.
Stopping behaviour
P68 and P69 = 1: Coast to Stop, P68 and P69 = 0: Coast to Stop
P68 and P69 = 1: Coast to Stop, P68 and P69 = 0: Stop and Switch Off
P68 and P69 = 1: Stop and Switch Off, P68 and P69 = 0: Stop and Switch Off
P68 and P69 = 1: Emergency Stop and Switch Off, P68 and P69 = 0: Stop and
DC brake
DC brake (only if P30 = 110): As from standstill, the direct current P631 (brak-
ing current) is impressed for the time of P632 (braking time).
Via P68 (Start Clockwise) and P69 (Start Anticlockwise) the motor stopping behavior is
controlled. For state P68 and P69 = logic 1, a stopping behavior must be selected. For
state P68 and P69 = logic 0, a stopping behavior must be selected.
1
Nominal value of frequency inverter
89
After first commissioning 06/2013 Operating Instructions
Agile
