Branson 2000Xc - Page 258

100-412-234 REV. 06 245
250
Abs S/R
Limit Cross
The plus reject
absolute distance limit is
equal to or less than the
minus suspect absolute
distance limit.
Change the +reject absolute
distance or
- suspect absolute distance
limit through the Alarm
Information screen or Setup
menu.
251
Abs S/R
Limit Cross
The plus suspect
absolute distance limit is
equal to or less than the
minus reject absolute
distance limit.
Change the +suspect absolute
distance or
- reject absolute distance limit
through the Alarm Information
screen or Setup menu.
252
Abs S/R
Limit Cross
The plus reject
absolute distance limit is
equal to or less than the
plus suspect absolute
distance limit.
Change the +reject absolute
distance or
+suspect absolute distance
limit through the Alarm
Information screen or Setup
menu.
253
Abs S/R
Limit Cross
The minus reject absolute
distance limit is equal to or
greater than the minus
suspect absolute distance
limit.
Change the - reject absolute
distance limit or the - suspect
absolute distance limit through
the Alarm Information screen
or Setup menu.
254
Col S/R
Limit Cross
The plus reject
collapse distance limit is
equal to or less than the
minus suspect collapse
distance limit.
Change the +reject collapse
distance limit or - suspect
collapse distance limit through
the Alarm Information screen
or Setup menu.
255
Col S/R
Limit Cross
The plus suspect
collapse distance limit is
equal to or less than the
minus reject collapse
distance limit.
Change the +suspect collapse
distance limit or - reject
collapse distance limit through
the Alarm Information screen
or Setup menu.
256
Col S/R
Limit Cross
The plus reject collapse
distance limit is equal to or
less than the plus suspect
collapse
distance limit.
Change the +reject collapse
distance limit or +suspect
collapse distance limit through
the Alarm Information screen
or Setup menu.
257
Col S/R
Limit Cross
The minus reject
collapse distance limit is
equal to or greater than the
minus suspect collapse
distance limit.
Change the - reject collapse
distance limit or - suspect
collapse distance limit through
the Alarm Information screen
or Setup menu.
258
F S/R Limit
Cross
The plus reject force limit is
equal to or less than the
minus suspect force limit.
Change the +reject force limit
and/or the - suspect force limit
through the Alarm Information
screen or Setup menu.
Table B.5 Setup Alarms and Messages, with Probable Cause and Corrective Action (Continued)
Alarm
ID
Display
Message
Alarm Condition/Cause Corrective Action
