250 100-412-234 REV. 06
22B
Amp Step
Conflict
The amplitude step at
collapse distance is equal to
or greater than the collapse
distance.
Change the amplitude step or
collapse distance through the
Alarm Information screen or
Setup menu.
22C
Amp Step
Conflict
The amplitude step at time
value is equal to or greater
than the maximum timeout
value. This occurs in all
modes except time.
Change the amplitude step at
time value and/or the
maximum timeout value
through the Alarm Information
screen or Setup menu.
22D
+ - Trg
Limit
Crossed
The reject limits for trigger
distance that you have
entered are reversed.
Change the reject trigger
distance limits through the
Alarm Information screen or
Setup menu.
22E
+ - Trg
Limit
Crossed
The suspect limits for
trigger distance that you
have entered are reversed.
Change the suspect trigger
distance limits through the
Alarm Information screen or
Setup menu.
22F
Preset Not
Available
Preset is recalled via
external inputs and the
preset is not defined or is
not allowed for the control
level.
Check control level availability
for preset.
Preset is not defined.
Make sure presets do not
exceed 16.
23A
+R Trg >
+R Abs
The plus reject trigger limit
is equal to or greater than
the plus reject absolute
distance limit.
Change the +reject trigger
limit and/or the +reject
absolute distance limit through
the Alarm Information screen
or Setup menu.
23B
Timeout
Conflict
The plus suspect time limit
is equal to or greater than
the
maximum timeout value.
Change the +suspect time limit
or maximum timeout value
through the Alarm Information
screen or Setup menu.
23C
Cutoff
Conflict
The minus reject power
limit is equal to or greater
than the peak power cutoff
value.
Change the - reject power limit
or peak power cutoff through
the Alarm Information screen
or Setup menu.
23D
Cutoff
Conflict
The plus reject power limit
is equal to or greater than
the peak power cutoff
value.
Change the +reject power limit
or peak power cutoff through
the Alarm Information screen
or Setup menu.
23E
Cutoff
Conflict
The minus suspect power
limit is equal to or greater
than the peak power cutoff
value.
Change the - suspect power
limit or peak power cutoff
through the Alarm Information
screen or Setup menu.
Table B.5 Setup Alarms and Messages, with Probable Cause and Corrective Action (Continued)
Alarm
ID
Display
Message
Alarm Condition/Cause Corrective Action
