100-412-234 REV. 06 255
2DF
Energy
Comp
Conflict
The plus suspect energy
limit is equal to or greater
than the energy
compensation maximum
value.
Change the +Suspect energy
limit or maximum energy
compensation through the
Alarm Information screen or
Setup menu.
2E2
- S Trg >
+S Abs
The minus suspect trigger
limit is equal to or greater
than the plus suspect
absolute limit.
Change the - suspect trigger
limit and/or the +suspect
absolute limit through the
Alarm Information screen or
Setup menu.
2E4
- R Trg >
+S Abs
The minus reject trigger
limit is greater than or
equal to the plus suspect
absolute distance limit.
Change the - reject trigger limit
and/or the +suspect absolute
distance limit through the
Alarm Information screen or
Setup menu.
2E5
- R Trg >
+R Abs
The minus reject trigger
limit is greater than or
equal to the plus reject
absolute distance limit.
Change the - reject trigger limit
and/or the +reject absolute
distance limit through the
Alarm Information screen or
Setup menu.
2E6
- S Trg >
Abs
The minus suspect trigger
limit is greater than or
equal to the absolute
distance.
Change the - suspect trigger
limit and/or the absolute
distance through the Alarm
Information screen or Setup
menu.
2E7
- R Trg >
Abs
The minus reject trigger
limit is greater than or
equal to the absolute
distance.
Change the - reject trigger limit
and/or the absolute distance
through the Alarm Information
screen or Setup menu.
2E9
Ext U/S
Delay
Conflict
External trigger delay and
pretrigger are both on.
Turn one off.
2EA
Ext U/S
Delay
Conflict
External trigger delay has
been enabled in weld setup,
but no input pin has been
defined.
Assign pin in System
Configuration Menu.
2EB
Part Clamp
Setup
Either the input or output
pin is not defined.
Assign a pin in the system
configuration menu.
2EF Sync Setup
The sync input pin and the
sync output pin are not both
defined.
Define missing sync pin.
2F0 Ext Signal
Ext Start requires both an
input pin and an output pin
to function. One of the pins
is not defined.
Define both and input and an
output pin for the SV Interlock.
Table B.5 Setup Alarms and Messages, with Probable Cause and Corrective Action (Continued)
Alarm
ID
Display
Message
Alarm Condition/Cause Corrective Action
