RFDR
User Manual Version 002 BRUKER BIOSPIN 139 (327)
Data Acquisition 10.3
Sample:
13
C fully labelled histidine.
Experiment time: Several hours.
Set-up 2D Experiment 10.3.1
After 1D parameter optimization as previously described, type iexpno to create a
new data file and switch to the 2D mode using the “123” button. Set the appropri
-
ate FnMode parameter in eda. Pulse program parameters are indicated below
(
Figure 10.1. shows the pulse sequence).
Figure 10.2. The “123” Icon in the Menu Bar of the Data Windows Acquisition Pa-
rameter Page
The “123” icon in the menu bar of the data windows acquisition parameter page
(see
Figure 10.2.)is used to toggle to the different data acquisition modes, 1D, 2D
and 3D if so desired.
