288 (327) BRUKER BIOSPIN User Manual Version 002

Modified W-PMLG

Fine Tuning for Best Resolution 23.5

Fine tuning is done by optimizing power levels, pulse widths and carrier offset as

before, the carrier spike is gone, spikes at both sides may appear.

Correcting for Actual Spectral Width 23.6

The modified sequence has a slightly different scaling factor of 0.47.

Table 23.3. DUMBO, Analog Mode

Parameter Value Comment

pulprog dumboa2 Runs on AV 3 instruments only.

pl12

sp1

For 100 kHz RF field

up to 130 kHz To be optimized during setup.

spnam1 dumbo1_64 Set by xau dumbo.

p1 2.5 µsec For 100 kHz RF field.

p8 1.2µsec

p9 4 – 2.6 µsec To be optimized.

p10 32 µsec or 24 µsec Set by xau dumbo.

d1 4s For α-glycine.

l11=anavpt 4 2, 4, 8, 16 or 32.

o1p 5 To be optimized.

swh 1e

/2*(2*p9+p10)*0.5 To be corrected for proper scaling.

rg 16-64

td 512 Up to 1024.

si 4k

digmod analog

MASR 10-12 kHz Depending on cycle time.
