174 (327) BRUKER BIOSPIN User Manual Version 002

SUPER

Spectral Processing 13.5

Table 13.2. Processing Parameters

Parameter Value Comment

F1 acquisition

C Left column.

SI 4096 Number of points and zero fill.

WDW QSINE Squared sine bell.

SSB 2 90º shifted sine bell.

PH_mod pk Phase correction if needed.

BC_mod quad DC offset correction.

Alpha -1 For shearing the spectrum.

F2 indirect

C Right column.

SI 128 Zero fill.

MC2 STATES-TPPI

WDW QSINE Squared sine bell.

SSB 2 90º shifted sine bell.

PH_mod pk Phase correction if needed.

BC_mod no Automatic baseline correction.
