256 (327) BRUKER BIOSPIN User Manual Version 002

Double-CP

Pulse Sequence Diagram, Double CP (DCP) 20.1

Figure 20.1. Pulse sequence diagram for 1D (t

=0) and 2D double CP experi-

ments.

Double CP Experiment Setup 20.2

Double CP 2D Experiment Setup 20.2.1

1. Prepare your probe for triple resonance applications H/C/N

2. Load a sample of glycine,

N and C

,-C

(or only C

C labelled. Make sure

the sample is α-glycine, you will get nowhere with γ-glycine, since the proton

1ρ

is very short and CP just does not work with high efficiency. Rotate at 11

kHz. The sample may be fully labelled or diluted with natural abundance gly

cine. A restricted volume rotor is preferred. If a different spin rate is used, a dif-

ferent shape must be generated for the second CP step.

= 1, 3 φ

= 0 + States-TPPI (t

) φ

= 0 0 0 0 1 1 1 1

2 2 2 2 3 3 3 3

rec

=0 2 2 0 3 1 1 3

2 0 0 2 1 3 3 1

= 0 0 0 0 2 2 2 2
