Additional Connections for VT Operation

User Manual Version 002 BRUKER BIOSPIN 39 (327)

Figure 3.30. Bottom view of Low Temperature DVT Probe/Heat Exchanger

1. Gas in

2. Frame flush

3. Shims

4. Spin rate

5. Heater

6. Magnet bore

7. Transfer line

8. Read and regulation thermocouples

9. Support for transfer line
