188 (327) BRUKER BIOSPIN User Manual Version 002

Symmetry Based Recoupling

Spectral Processing 14.4

Processing Parameters

Processing parameters for DQ-SQ correlation experiments using symmetry

based recoupling sequences. The AU program xfshear may be used with option

rotate and argument(+/- δ ppm) to shift the spectrum suitably along F1. Setting 1

sr = 2*sr+o1 will set the referencing along F1 correctly (just type sr, and in f1 en

ter the value of sr for F2 and add *2+o1).

Table 14.3. Processing parameters for DQ-SQ correlation experiments using symmetry based recou-

pling sequences

Parameter Value Comment

F1 acquisition

C (left column)

SI 2-4 k Number of points and zero fill

WDW QSINE Sine bell squared

SSB 2-5 Shifted sine bell

PH_mod pk Phase correction if needed

F2 indirect

C (right column)

SI 256-1024 Zero fill

MC2 STATES-TPPI

WDW QSINE Sine bell squared

SSB 2 90º shifted sine bell
