Section 7. Installation
• It does not generate datalogger programs.
• It does not understand distances or topography; that is, it does not warn
when broadcast distances are exceeded, nor does it identify obstacles to
radio transmission.
For more detailed information on Network Planner, please consult the LoggerNet
manual, which is available at www.campbellsci.com.
7.5.1.2.2 Basics — Network Planner
PakBus Settings
• Device addresses are automatically allocated but can be changed.
• Device connections are used to determine whether neighbor lists should
be specified.
• Verification intervals will depend on the activities between devices.
• Beacon intervals will be assigned but will have default values.
• Network role (for example, router or leaf node) will be assigned based on
device links.
Device Links and Communication Resources
• Disallow links that will not work.
• Comparative desirability of links.
• Prevent over-allocation of resources.
• Optimal RS-232 and CS I/O ME baud rates based on device links.
• Optimal packet-size limits based on anticipated routes.
Fundamentals of Using Network Planner
• Add a background (optional)
• Place stations, peripherals, etc.
• Establish links
• Set up activities (scheduled poll, callback)
• Configure devices
• Configure LoggerNet (adds the planned network to the LoggerNet
Network Map)
