Campbell CR800 Series User Manual

Section 8. Operation
341
CalDiffOffset() Field Descriptions
Field
±mV Input
Range
Integration
CalDiffOffset(13) 5000 50 Hz Rejection
CalDiffOffset(14) 2500 50 Hz Rejection
CalDiffOffset(15) 250 50 Hz Rejection
CalDiffOffset(16) 25 50 Hz Rejection
CalDiffOffset(17)
7.5
50 Hz Rejection
CalDiffOffset(18) 2.5 50 Hz Rejection
Calibrate() Instruction Results
Cal()
Array
Field
Descriptions of Array Elements
Typical Value
Differential (Diff)
Single-Ended (SE)
Offset or Gain
±mV Input
Range
Integration
1
SE
Offset 5000 250 ms ±5 LSB
2
Diff
Offset 5000 250 ms ±5 LSB
3 Gain 5000 250 ms –1.34 mV/LSB
4 SE Offset 2500 250 ms ±5 LSB
5 Diff Offset 2500 250 ms ±5 LSB
6 Gain 2500 250 ms –0.67 mV/LSB
7 SE Offset 250 250 ms ±5 LSB
8 Diff Offset 250 250 ms ±5 LSB
9 Gain 250 250 ms –0.067 mV/LSB
10 SE Offset 25 250 ms ±5 LSB
11 Diff Offset 25 250 ms ±5 LSB
12 Gain 25 250 ms –0.0067 mV/LSB
13 SE Offset 7.5 250 ms ±10 LSB
14 Diff Offset 7.5 250 ms ±10 LSB
15 Gain 7.5 250 ms –0.002 mV/LSB
16 SE Offset 2.5 250 ms ±20 LSB
17 Diff Offset 2.5 250 ms ±20 LSB
18 Gain 2.5 250 ms –0.00067 mV/LSB
19 SE Offset 5000 60 Hz Rejection ±5 LSB
20 Diff Offset 5000 60 Hz Rejection ±5 LSB
21 Gain 5000 60 Hz Rejection –0.67 mV/LSB
