Campbell CR800 Series - Analog Voltage Input Ranges and Options

Section 8. Operation
346
measurements. The first measurement determines the range to use. It is made
with a 250 µs integration on the ±5000 mV range. The second measurement is
made using the range determined from the first. Both measurements use the
settling time entered in the SettlingTime parameter. Auto-ranging optimizes
resolution but takes longer than a measurement on a fixed range because of the
two-measurement sequences.
An auto-ranged measurement will return NAN ("not a number") if the voltage
exceeds the range picked by the first measurement. To avoid problems with a
signal on the edge of a range, AutoRange selects the next larger range when the
signal exceeds 90% of a range.
Use auto-ranging for a signal that occasionally exceeds a particular range, for
example, a type-J thermocouple measuring a temperature usually less than 476 °C
(±25 mV range) but occasionally as high as 500 °C (±250 mV range).
AutoRange should not be used for rapidly fluctuating signals, particularly signals
traversing multiple voltage ranges rapidly. The possibility exists that the signal
can change ranges between the internal range check and the actual measurement.
Analog Voltage Input Ranges and Options
Range Code Description
mV5000
measures voltages between ±5000
mV
mV2500
1
measures voltages between ±2500
mV
mV250
2
measures voltages between ±250 mV
mV25
2
measures voltages between ±25 mV
mV7_5
2
measures voltages between ±7.5 mV
mV2_5
2
measures voltages between ±2.5 mV
AutoRange
3
datalogger determines the most
suitable range
1
Append with C to enable common-mode null / open-input detect and set
excitation to full-scale (~2700 mV) (Example: mV2500)
2
Append with C to enable common-mode null / open-input detect (Example:
mV25C)
3
Append with C to enable common-mode null / open-input detect on ranges ≤
±250 mV, or just common-mode null on ranges > ±250 mV (Example:
AutoRangeC)
Input Limits / Common-Mode Range
Related Topics:
• Voltage Measurements — Specifications
• Voltage Measurements — Overview
(p. 65)
• Voltage Measurements — Details
(p. 345)
