Section 4. Quickstart
10. Only one table is needed for this tutorial, so remove Table 2. Click 2 Table2
tab, then click Delete Table.
11. Change the name of the remaining table from Table1 to OneMin, and then
change the Store Every interval to 1 Minutes.
12. Add measurements to the table by selecting BattV under Selected Sensors in
the center pane. Click Average in the center column of buttons. Repeat this
procedure for PTemp_C and Temp_C.
4.6.4.5 Procedure: (Short Cut Steps 13 to 14)
13. Click Finish at the bottom of the Short Cut window to compile the program.
At the prompt, name the program MyTemperature. A summary screen, like
the one in the following figure, will appear showing the pre-compiler results.
Pre-compile errors, if any, are displayed here.
FIGURE 6: Short Cut Compile Confirmation Window and Results Tab
14. Close this window by clicking on X in the upper right corner.
4.6.5 Send Program and Collect Data
PC200W Datalogger Support Software objectives:
• Send the CRBasic program created by Short Cut in the previous
procedure to the CR800.
