Section 4. Quickstart
4.6.4.1 Procedure: (Short Cut Steps 1 to 5)
1. Click on the Short Cut icon in the upper-right corner of the PC200W window.
The icon resembles a clock face.
2. The Short Cut window is shown. Click New Program.
3. In the Datalogger Model drop-down list, select CR800.
4. In the Scan Interval box, enter 1 and select Seconds in the drop-down list
box. Click Next.
Note The first time Short Cut is run, a prompt will appear asking for a
choice of ac noise rejection. Select 60 Hz for the United States and other
areas using 60 Hz ac voltage. Select 50 Hz for most of Europe and other
areas that operate at 50 Hz. A second prompt lists sensor support options.
Campbell Scientific, Inc. (US) is probably the best fit if you are outside
Europe.
5. The next window displays Available Sensors and Devices as shown in the
following figure. Expand the Sensors folder by clicking on the symbol.
This shows several sub-folders. Expand the Temperature folder to view
available sensors. Note that a wiring panel temperature (PTemp_C in the
Selected column) is selected by default.
FIGURE 4: Short Cut Temperature Sensor Folder
